동풍 9.1큐브 유화 아스팔트 포장기, 도로 유지보수용 지능형 아스팔트 포장기

    동풍 4X2 9.1CBM 230마력 아스팔트 포장기는 모든 아스팔트 포장 작업에서 탁월한 정밀도를 제공하도록 특별히 설계된 고성능 아스팔트 포설 장비입니다. 다재다능하고 적응성이 뛰어난 이 장비는 고속도로, 도심 도로, 주차장 등 다양한 프로젝트에 완벽하게 적합하며, 최첨단 연구 개발 기술과 견고한 제조 역량을 완벽하게 결합하여 뛰어난 내구성과 운영 효율성을 보장합니다. 230마력의 고성능 엔진으로 구동되는 이 포장기는 까다로운 시공 환경에서도 일관되고 강력한 출력을 제공하여 전 세계 전문 건설업체들이 선호하는 장비입니다. 탄탄한 글로벌 판매 실적을 자랑하는 이 장비는 탁월한 신뢰성, 뛰어난 다용성, 그리고 모든 아스팔트 포장 작업에서의 일관된 성능으로 폭넓은 신뢰를 얻고 있습니다. 동풍의 중장비 제조 분야에서 축적된 전문성을 바탕으로 제작된 4X2 9.1CBM 아스팔트 포장기는 모든 생산 공정에서 최고 수준의 산업 표준을 엄격히 준수합니다. 이 제품은 시장의 기대를 충족할 뿐만 아니라 뛰어넘으며, 글로벌 아스팔트 포장기 시장을 선도하는 제품으로 자리매김하고 있습니다.
    청소 방법

    하이공(후베이) 수입 수출 유한 회사


    슬로건: 해공을 선택하세요, 성공을 선택하세요

    회사 소개


    비전: 트럭 사업의 원동력이 되는 것


    하이공(후베이) 수출입 유한회사는 중국 특수 목적 차량의 중심지로 유명한 쑤이저우에 깊이 뿌리내리고 있습니다. 당사는 중국 상용 트럭의 해외 무역 부문에만 집중하며, 상용 트럭 관련 기업의 해외 진출을 지원하고 쑤이저우의 완벽한 특수 목적 차량 산업망을 활용하여 중국과 세계 시장을 잇는 상용 트럭 비즈니스 가교를 구축하는 것을 핵심 사명으로 삼고 있습니다.


    수년간 축적된 심도 있는 업계 경험과 자원 활용을 바탕으로, 당사는 다양하고 성숙한 사업 시스템을 구축했습니다. 시장 수요를 정확하게 충족하고 중국 트럭 수출 고객에게 브랜드 육성 솔루션을 제공하여 모든 거래업체가 제품뿐 아니라 강력한 시장 경쟁력까지 확보할 수 있도록 지원합니다.


    당사는 전문적인 조달 대행 서비스 시스템을 통해 국내 트럭 수출의 전 과정(주요 공장의 섀시, 특수 차량 상부 구조/KD 부품 및 액세서리, 운송 및 포장, 수출 허가, 통관 신고, 해상 보험 포함)에서 발생하는 일반적인 문제점, 즉 주요 공장의 국제적인 지역 보호 정책으로 인한 수출 경로 차단, 단일 제품 구조(특수 차량 상부 구조), 불충분한 수출 경쟁력, 복잡한 정책 및 규정 등을 해결합니다.
    In summary, the Dongfeng 4X2 9.1-CBM 230(HP) Asphalt Paver stands out as a reliable, efficient, and innovative solution for modern paving needs. Its advanced technology, robust manufacturing quality, and proven track record make it an essential asset for any road paving operation. It also serves as a testament to Dongfeng’s commitment to quality and innovation in the field of paving technology.
    Note: Asphalt Paver is also known as Asphalt Spreader, Road Paver, and Asphalt Paving Machine.

    .

    Left anterior oblique view of Asphalt Paver(Asphalt Spreader,Road Paver,Asphalt Paving Machine)


    Dongfeng 9.1-CBM Emulsified Asphalt Paver

    Left view of Asphalt Paver(Asphalt Spreader,Road Paver,Asphalt Paving Machine

    Intelligent Emulsified Asphalt Paver


    Left rear oblique view of Asphalt Paver(Asphalt Spreader,Road Paver,Asphalt Paving Machine

    9.1-CBM Road Maintenance Paver


    Right anterior oblique view of Asphalt Paver(Asphalt Spreader,Road Paver,Asphalt Paving Machine)

    Dongfeng 9.1-CBM Emulsified Asphalt Paver


    Main Configuration
    Dongfeng D9 4x2 Intelligent Asphalt Spreader
    Product nameAsphalt Spreader
    Vehicle modelCL5180GLQ6LS
    Chassis nameDongfeng D9 Dolica
    Wheelbase4500mm
    Number of axles2
    Engine modelYCS04200-68, B6.2NS6B230 are available
    Engine horsepowerYuchai 200 horsepower, Cummins 230 horsepower are available
    Engine displacement4000ml, 6200ml
    Tire specifications10.00R20 Steel Wire Tire
    Number of tires6+1 (pcs)
    Fuel typeDiesel
    Fuel tank capacity180 (L)
    GearboxShaanxi Gear 8-speed Transmission
    Number of passengers2, 3 (pcs)
    Maximum speed105 (km/h)
    Gross mass (kg)18000
    Curb mass (kg)9450
    Rated load (kg)8420
    Insulation layerRock Wool
    Vehicle size (mm)8420*2500*3330
    Thermal oil pumpR Y40-25-160
    Proportional valveCL-BLTS120.00
    Temperature sensorWZP-230
    Stop valvePN16DN50
    Operation methodOperation in the cab
    Nozzle control methodOne control one
    Tail nozzle36 pneumatic asphalt nozzles
    Asphalt spreading amount0.25-3L/m² (error ±2%)
    Thermal oilWith heat transfer oil circulation heating
    Tank volume (L)10000-11500
    Tank materialQ235 high-quality carbon steel
    Tank surfaceStainless steel
    FilterCustomized
    Handheld spray gun6m hose + spray gun
    Asphalt pumpQGB950
    Asphalt pump flow rate950L/min
    Spraying mediumEmulsified asphalt, hot asphalt
    Spraying width (m)4.5m (optional 6m spray rod)
    Spraying area calculationSpraying area = tank volume ÷ spraying amount
    Cleaning methodBuilt-in pneumatic cleaning or diesel cleaning


    Haigong (Hubei) Import and Export Co.


    Slogan: CHOOSE HAIGONG, CHOOSE SUCCESS

    About Us

    Vision: To be the engine of the truck business

    Haigong (Hubei) Import and Export Co., Ltd. is deeply rooted in Suizhou, the renowned "Capital of Special Purpose Vehicles in China". We focus exclusively on the foreign trade sector of China's commercial trucks, with our core mission being to empower commercial truck-related enterprises to expand overseas and build a business bridge for commercial trucks between China and the global market, leveraging Suizhou's complete supporting industrial chain of special purpose vehicles.
    Backed by years of in-depth industry experience and resource accumulation, the company has established a diversified and mature business system. We accurately meet market demands and provide customers with brand incubation solutions for China's truck exports, ensuring that every trader sells not only products, but also strong market competitiveness.
    We address the common pain points in the full chain of domestic truck exports (including chassis from main factories, special vehicle superstructures/KD parts & accessories, transportation & packaging, export licenses, customs declaration, and marine insurance), such as blocked export channels (due to main factories' international regional protection policies), single product structure (special vehicle superstructures), insufficient export competitiveness, and complex policies and regulations, through our professional "procurement agency" service system.

    Intelligent Emulsified Asphalt Paver


    내장형 공압식 청소 또는 디젤식 청소

    귀하의 회사는 공장 회사인가요, 아니면 무역 회사인가요?

    저희는 중국 내 특수 트럭, 탱커, 트레일러 및 예비 부품의 선도적 제조업체입니다. 중국 특수 목적 차량 생산 기지인 수이저우시에 있는 저희를 방문해 주시기 바랍니다.

    지불 조건은 무엇인가요?

    T/T 30-50%는 보증금으로, 나머지는 배송 전입니다. 잔액을 지불하기 전에 제품과 패키지의 사진을 보여드리겠습니다.

    귀사의 배송 조건은 무엇입니까?

    수출통관, 본선 인도, 미국 연방 공보부(FFR), 국제이주연맹(CIIF), 다프, 영어: DDU는 영어이다..

    배송 시간은 어떨까요?

    일반적으로 선불금을 받은 후 20~30일이 걸립니다. 구체적인 배송 시간은 품목과 주문 수량에 따라 달라집니다.

    내 요구 사항에 맞게 제품을 맞춤 제작할 수 있나요?

    네. 저희는 전문적인 R&D 팀을 보유하고 있어서 귀하의 요구 사항에 정확히 맞춰 제품을 생산할 수 있습니다.

    귀하의 제품 가격은 얼마인가요?

    우리는 공장에서 직접 판매하므로 가격이 매우 경쟁력이 있습니다. 제품마다 가격이 다릅니다. 가격은 또한 귀하의 특별한 요구 사항에 따라 달라집니다. 정확한 가격을 알고 싶으시면 저희에게 연락하세요!

    배송 전에 모든 상품을 테스트하시나요?

    네, 배송 전 100% 테스트를 거칩니다.

    어떤 서비스를 받으실 수 있나요?

    저희는 모든 제품에 대해 평생 추적 서비스와 1년 무료 보증을 제공합니다. 그 사이에 저희는 귀하의 제품을 수리하는 데 도움이 되는 무료 교육 및 기술 지원을 제공합니다. 필요한 경우 원래 예비 부품도 공급해 드리며 운임만 지불하시면 됩니다.
